* Heating Capacity at Air 26℃, Humidity 80%, Water 26℃ in, 28℃ out

Heating Capacity (kW)

7.6~1.7

9.5~2.3

13~3.0

17~3.8

21~4.8

28~6.8

35~8.8

28~6.8

35~8.8

Power Input (kW)

1.12~0.11

1.40~0.15

1.91~0.19

2.5~0.24

3.09~0.30

4.12~0.43

5.15~0.56

3.97~0.43

5.15~0.56

COP

15.8~6.8

15.8~6.8

16~6.8

15.8~6.8

15.8~6.8

15.8~6.8

15.8~6.8

15.8~6.8

15.8~6.8

* Heating Capacity at Air 15℃, Humidity 70%, Water 26℃ in, 28℃ out

Heating Capacity (kW)

6.1~1.4

7.6~1.9

9.8~2.3

13.5~3

16.5~3.8

23~5.5

25.5~6.4

23~5.5

25.5~6.4

Power Input (kW)

1.24~0.18

1.55~0.25

1.96~0.30

2.76~0.39

3.37~0.5

4.7~0.72

5.2~0.84

4.7~0.72

5.2~0.84

COP

7.6~4.9

7.6~4.9

7.6~5

7.6~4.9

7.6~4.9

7.6~4.9

7.6~4.9

7.6~4.9

7.6~4.9

* Cooling Capacity at Air 35℃,  Water 29℃ in, 27℃ out

Cooling Capacity (kW)

4.2~1.0

5.3~1.3

7.2~1.7

9.4~2.1

11.6~2.7

14.9~3.8

19.3~4.9

14.9~3.8

19.3~4.9

Power Input (kW)

1.11~0.15

1.4~0.19

1.89~0.25

2.47~0.31

3.05~0.4

3.92~0.57

5.08~0.73

3.92~0.57

5.08~0.73

EER

6.6~3.8

6.7~3.8

6.7~3.8

6.7~3.8

6.7~3.8

6.7~3.8

6.7~3.8

6.7~3.8

6.7~3.8

* General data

Power supply

220~240V/1/50Hz

380~415V/3/50Hz

Max Power Input (kW)

1.55

1.78

2.2

2.6

3.2

4.45

4.76

6.43

6.93

Max Current (A)

7.3

8.3

10.2

12

14.7

20.4

30

7.9

11.3

Water Flow Volume (m3/h)

2.5

3.5

4.5

5.5

6.5

9

12

9

12

Refrigerant

R32

Heat Exchanger

Titanium

Air Flow Direction

Horizontal

Automatic defrosting

by 4 way valve

Working temp. range (℃)

-15~43

Casing Material

ABS

Water Proof Level

IPX4

Noise level 1m dB(A)

39~49

40~52

42~53

43~55

45~56

47~58

49~59

47~58

49~59

Noise level 10m dB(A)

20~29

20~32

22~33

23~35

25~36

27~38

29~39

27~38

29~39

Net Weight (kg)

42

43

53

54

58

88

98

88

98

Gross Weight (kg)

53

54

64

65

69

99

110

99

110

Net Dimensions (mm)

864*349*592

925*364*642

1084*399*737

Package Dimensions (mm)

930*400*640

990*435*760

1146*460*862
